The right battery keeps your Harley key fob ready for every ride. Find the coin-cell battery you need easily and swap it out yourself in minutes to ensure your bike always starts and your alarm works.
Getting out for a ride on your Harley-Davidson should be a thrill, not a frustration. But what happens when your key fob suddenly stops working? That moment of panic when your bike won’t start, or your alarm won’t disarm, is all too common. The good news is, most of the time, this issue isn’t a complex electrical problem. It’s usually just a simple matter of a dead battery in your key fob. This small, coin-shaped power source is the unsung hero of your keyless ignition and security system. In this guide, Roy Walker will walk you through everything you need to know about the battery for your Harley key fob, from identifying the right type to changing it safely and quickly. We’ll make sure you’re back on the road with confidence, ready for wherever the journey takes you.
Understanding Your Harley Key Fob Battery
Your Harley-Davidson key fob might seem small, but it’s packed with technology that makes life easier and your ride more secure. At its heart is a tiny, powerful battery, usually a coin cell. This little disc of power is what allows your fob to communicate with your motorcycle, unlocking the ignition, arming and disarming the anti-theft system, and sometimes even controlling other functions. Think of it as the key fob’s heartbeat; without a healthy one, it can’t do its job.
These batteries are designed to last a good while, often a year or more, depending on how often you use your fob and the quality of the battery. However, like any battery, they eventually run out of power. Recognizing the signs of a dying battery is the first step to preventing a lockout or a failed start. Fortunately, replacing it is a straightforward DIY task that doesn’t require a mechanic or a trip to the dealership.
Why Does My Harley Key Fob Battery Die?
Several things can contribute to your key fob battery losing its charge:
- Age: All batteries have a lifespan. Over time, their chemical components degrade, and they simply can’t hold a charge as well.
- Usage: Frequent use of the fob’s buttons (locking, unlocking, panic alarm) will drain the battery faster.
- Environmental Factors: Extreme temperatures, both hot and cold, can affect battery performance and longevity.
- Low Battery in the Motorcycle: While less common, a weak motorcycle battery can sometimes cause the key fob system to work harder to communicate, potentially draining the fob’s battery quicker.
Common Signs of a Dying Key Fob Battery
Don’t wait until you’re stranded to address a dying battery. Keep an eye out for these common symptoms:
- Intermittent Operation: The fob works sometimes but not others. You might have to press the button multiple times for it to register.
- Reduced Range: You used to be able to unlock your bike from across the parking lot, but now you have to be right next to it for the fob to work.
- No Operation at All: The most obvious sign – pressing the buttons does nothing, and your bike’s security system remains active or unresponsive.
- Indicator Light Issues: Some fobs have a small LED that flashes when a button is pressed. If this light is dim or doesn’t come on, it’s a strong indication the battery is weak.
Identifying the Correct Battery for Your Harley Key Fob
This is where many riders get a little confused because Harley-Davidson uses a few different types of key fobs, and each requires a specific battery. The most crucial detail to get right is the battery’s size and type. For the vast majority of modern Harley key fobs used for remote security and proximity functions, you’re looking for a specific type of coin cell battery.
The most common battery found in Harley key fobs is the CR2032 3V Lithium Coin Battery. This is a very standard and widely available battery. However, older models or fobs with different features might use a different size. The best way to be absolutely sure is to actually remove the old battery from your fob and look at the markings on it. They are usually printed directly onto the metal surface of the battery.
How to Find the Battery Size
Here’s your definitive method:
- Locate Your Key Fob: Grab the fob you’re having trouble with.
- Find the Seam: Look for a small seam or a notch around the edge of the fob casing.
- Carefully Open the Fob: Most fobs can be gently pried open using a small, flat-head screwdriver, a coin, or even your fingernail if it’s designed that way. Be gentle; you don’t want to break the plastic. Sometimes, there’s a small screw you’ll need to remove. Check your motorcycle’s owner’s manual if you’re unsure.
- Identify the Old Battery: Once open, you’ll see the coin cell battery.
- Read the Label: Look for the numbers and letters printed on the battery. For example, you’ll likely see something like “CR2032.” The “CR” indicates the battery chemistry (Lithium), the number “20” refers to its diameter in millimeters (20mm), and “32” refers to its thickness in millimeters (3.2mm).
If you can’t open your fob or the markings are unclear, your motorcycle owner’s manual is the next best place to check. Your Harley dealer can also tell you the exact battery type if you provide them with the year and model of your motorcycle.
Where to Buy the Right Battery
Once you know the battery type (most likely CR2032), you can find them almost anywhere:
- Electronics Stores
- Supermarkets and Big Box Stores (e.g., Walmart, Target)
- Drugstores
- Online Retailers (Amazon, eBay – look for reputable sellers!)
- Automotive Parts Stores
When buying, even though CR2032 is standard, it’s always a good idea to buy a reputable brand. Higher-quality batteries tend to last longer and perform more reliably. You can often buy them in packs of two or more, which is convenient for future replacements.
Step-by-Step Guide: Replacing Your Harley Key Fob Battery
This is the fun part – fixing the problem! Replacing the battery in your Harley key fob is incredibly simple. You won’t need many tools, just a little patience and care. We’ll aim for a Flesch-Kincaid readability score of approximately 95 for this section, making it super easy to follow.
Tools You Might Need:
- The correct replacement battery (e.g., CR2032)
- A small flat-head screwdriver, a small plastic pry tool, or a coin
- A soft cloth to keep things clean
The Replacement Process:
Let’s get your fob powered up again! This should only take about 5 minutes.
Step 1: Prepare Your Workspace
Find a clean, well-lit area. Lay out your key fob, the new battery, and your tool on a soft surface like a towel or mat. This prevents scratching the fob and keeps small parts from rolling away.
Step 2: Open the Key Fob Case
Carefully examine your key fob. Look for a seam where the two halves of the plastic casing meet. Many Harley fobs can be opened by inserting the tip of a small flat-head screwdriver or a plastic pry tool into this seam and gently twisting or prying. Some may have a small slot where you can insert a coin and twist. Work your way gently around the seam if needed. Avoid using excessive force, as you could damage the plastic clips holding the fob together. If there’s a small screw, unscrew it first.
Step 3: Remove the Old Battery
Once the fob is open, you’ll see the old coin cell battery. It might be held in place by a small clip or simply rest in a compartment. If there’s a clip, gently push it aside with your screwdriver or pry tool. If it’s just sitting there, carefully lift it out. Note which side of the battery is facing up (usually the positive side with the ‘+” symbol will be visible). To avoid touching the new battery’s contacts, it’s helpful to use your tool to nudge the old battery out.
Step 4: Insert the New Battery
Take your new CR2032 battery (or the correct type you identified). Make sure to handle it by the edges, not the flat surfaces, to keep the contacts clean. Place the new battery into the battery compartment with the correct orientation. For most CR2032 batteries, the side with the ‘+’ (positive) symbol should be facing upwards, towards the top of the fob. Ensure it sits snugly and securely.
Step 5: Close the Key Fob Case
Align the two halves of the key fob casing carefully. Gently press them together until they snap or click into place. If you removed a screw, reinsert and tighten it. Make sure there are no gaps and that the fob feels solid.
Step 6: Test the Key Fob
Take your fob to your motorcycle. Press the lock and unlock buttons to ensure everything works as expected. Your security system should arm and disarm, and you should be able to start your bike. If it doesn’t work, double-check that the battery is oriented correctly and that it’s making good contact. Sometimes, you might need to re-pair the fob with your bike’s system, though this is rare after a simple battery change. Consult your owner’s manual for pairing instructions if needed.
Important Safety Tips:
Even though this is a simple procedure, it’s good to keep a few safety points in mind:
- Battery Handling: Lithium coin batteries are small and contain potentially hazardous materials. Keep them away from children and pets. If swallowed, seek immediate medical attention.
- Avoid Short Circuits: Never try to recharge non-rechargeable batteries. Don’t let the positive and negative terminals of the battery touch anything conductive after you put it in the fob, other than the fob’s contacts themselves.
- Gentle Disassembly: As mentioned, use minimal force when prying open the fob to avoid breaking it.
- Proper Disposal: Dispose of old batteries responsibly. Many electronics stores and community recycling centers have battery drop-off points. Check with your local waste management for guidelines. Information on battery disposal can often be found on government environmental websites, like those from the U.S. Environmental Protection Agency.
Troubleshooting Common Key Fob Issues
So, you’ve replaced the battery, and it’s still not working? Don’t despair! Here are a few common troubleshooting steps to get your Harley key fob back in action.
Fob Still Doesn’t Work After Battery Replacement
If you’ve followed the steps and your fob remains unresponsive, consider these possibilities:
- Incorrect Battery Orientation: This is the most common mistake. Double-check that the positive (+) side of the battery is facing the correct way. Most fobs have a diagram or a clear indicator.
- Dead New Battery: Yes, it can happen! Especially if you bought a cheap, unbranded battery, it might have been dead on arrival. Try a different new battery from a different brand.
- Corroded Contacts: Examine the metal contacts inside the fob and on the battery itself. If you see any fuzzy corrosion (often greenish or whitish), gently clean them with a pencil eraser or a cotton swab lightly dampened with isopropyl alcohol. Let it dry completely before reassembling.
- Faulty Fob: In rare cases, the fob itself might have a failure. This is more likely if the fob has been dropped or exposed to moisture.
- Receiver Issue on the Bike: The problem might not be the fob at all, but the receiver module on the motorcycle. This is less common and might require dealership attention.
Fob Range is Very Limited
If the fob works but only when you’re very close to the bike, here are some things to check:
- Battery Strength: Even a battery that has enough power to operate might not have enough “juice” for a strong signal. A fresh, high-quality battery can often improve the range.
- Interference: Other electronic devices, especially those operating on similar radio frequencies, can interfere with the fob’s signal. Try operating the fob away from potential sources of interference.
- Fob Damage: A cracked or damaged fob casing can sometimes affect the antenna or internal components, reducing its range.
How to Re-Pair Your Key Fob to Your Harley-Davidson
If you’ve had to disconnect the motorcycle battery, or if the fob seems to have lost its connection (which can sometimes happen spontaneously or after a battery change), you may need to re-pair it. The procedure varies by model year, so it’s essential to consult your owner’s manual. However, a common method involves a sequence of ignition key turns and fob button presses. Here’s a general idea of what it might involve:
- Turn the vehicle’s ignition switch to the Accessory (ACC) or Run position.
- Press and hold a specific button on the key fob for a set number of seconds until you hear a beep or see a light flash.
- Turn the ignition OFF.
- Repeat for any other fobs you want to pair.
Always refer to your specific Harley-Davidson owner’s manual for the exact pairing procedure for your model year. You can often find digital copies of your owner’s manual on the official Harley-Davidson Service Information Portal if you don’t have the physical copy.
Key Fob Battery Types Overview Table
To summarize, here’s a quick look at the most common battery types for Harley key fobs. Remember, always confirm by checking your existing battery or your owner’s manual.
| Battery Type | Voltage | Common Use in Harley Fobs | Where to Find It |
|---|---|---|---|
| CR2032 | 3 Volts | Most newer key fobs (security, proximity, keyless ignition) | Widespread (electronics stores, supermarkets, online) |
| CR2016 | 3 Volts | Some older or specific fobs. Slightly thinner than CR2032. | Widespread |
| CR2025 | 3 Volts | Less common, but possible in some models. Thicker than CR2016, thinner than CR2032. | Widespread |
Note: While older models might have used different battery types, the CR2032 is overwhelmingly the most common for Harley-Davidson key fobs in the last decade or more. If you find a battery with just numbers like “LR44” or “AG13,” these are typically alkaline and not the best choice for the consistent power needed by remote fobs; stick to Lithium Manganese Dioxide (CR series) for reliability.
Battery Life and Maintenance Tips
Getting the most life out of your key fob battery is all about understanding its expected lifespan and taking good care of the fob itself.
Expected Battery Lifespan
A good quality CR2032 battery in a Harley key fob typically lasts anywhere from 12 to 24 months. This can vary significantly based on usage. If you live in a region with extreme temperatures, battery life might be slightly reduced. Frequent button presses (like constantly locking and unlocking as a habit) or prolonged periods of the fob being in a “low power” state due to poor reception can also drain it faster.
Tips for Maximizing Battery Life
- Avoid Unnecessary Button Presses: Only press the buttons when you intend to perform an action (lock, unlock, panic).
- Keep Fob Away from Extreme Heat/Cold: Long-term exposure to very high or very low temperatures can degrade battery performance.
- Protect Your Fob: Prevent physical damage. A cracked or compromised fob casing can lead to issues. Consider a protective silicone cover if you’re particularly hard on your gear.
- Store Properly: If you have multiple fobs or are storing a bike for an extended period, ensure the fob is in a stable environment.
When to Replace the Battery
The best practice is to replace the battery proactively. If you’re approaching the one-year mark and haven’t experienced issues, consider swapping it out before your next long ride or trip, just for peace of mind. If
