For your battery to work, you need a connector. But, you know, there are thousands of battery types that are connected through various connectors. As a result, the topic is broad to discuss even though we have attempted to keep it brief and to the point.
One of the main reasons why people are interested in this topic is that they can use RC battery connectors to make electronic devices with different types of batteries. Thus, we will thoroughly discuss these types of battery connectors. As part of this discussion, we will also discuss some of the most popular battery connectors for mobile phones and cordless telephones. Now, onto the main topic.
RC Battery Connector Types
No products found.
Do you make electronic circuits? If your answer is yes, then you obviously understand the importance of the battery connector. Without using a battery connector, you cannot power an electric circuit to run a device.
Anyway, the easiest way of using a battery connector in a circuit means choosing an RC battery connector. With this connector, you will be able to fulfill your simple needs and the installation process is extremely straightforward. Besides, the RC battery connector comes with vast diversity. So, let’s know about the different types of RC connectors.
1. Deans Mini Connector
Deans mini is a solid little battery connector, which delivers a value ranging from 7A up to 12A. Though you can use it for up to 15A value forcibly, you should take care of any overheating issue to save it from damage.
2. EC2 Connector
This battery supports higher values ranging from 20A up to 30A. Actually, it is a smaller version of the EC battery connector series. However, you need a 2mm bullet pin to use this battery connector. Sadly, many other pins won’t work here.
3. JST Connector
JST battery connector is also known as JST RCY battery connector and supports only small batteries. Generally, the JST connector is used for a 1.5A battery and has a common value of 5A. Anyway, you can push the power up to 10A for using a battery.
4. Molex Connector
The Molex is found as one of the smallest battery connectors and costs less too. Similarly, the Molex connector supports only 1A or 2A power, which seems to be very low compared to other connectors. Since it has a low-sized structure, you need to handle it carefully to save it from any kind of damage. However, this connector is also called the JST PH-2 pin connector.
5. Servo Plugs Connector
The servo plugs connector can take a load of 3A that can lead up to 6A. If we look at the usability, most people like it for making their own servo connector and saving a lot of money. As a result, the servo plugs battery connector is shown as one of the best battery connector types.
6. XT30 Connector
Though you will find many copied versions of this connector in the market, the original has the best capability for a higher cost. Because the XT30 battery connector can take a 30A load that boosts up to 40A.
7. T-Plug or Deans Connector
The specialty of the T-plug connector is its build material. Because of making it from high-temperature nylon, this deans connector does not melt easily and has no reverse polarity. Usually, the T-plug battery connector comes with both male and female connectors.
8. EC3 Connector
The EC3 connector uses a 3mm bullet pin for connection and supports around 60A power. Unluckily, the EC3 battery connector is highly-priced and very hard to handle because of its plug-unplug system.
9. TRX Connector
This battery connector can also take the same load as the EC3 connector. And, the 60A TRX connector is suitable for Traxxas RC vehicles and boats. Nevertheless, the connector also supports other similar batteries.
10. XT60 Connector
The XT60 battery connector is graded as the best battery connector by many users. And, this connector can take up to 60A power.
11. Anderson Power Pole Connector
From an industrial perspective, the Anderson battery connector is considered the best electronic connector type. Besides, the housing quality of it is much better than the other connectors.
12. AS150 Connector
The AS150 battery connector is suitable for higher power applications and can handle up to 200A power. Gladly, this connector comes with nice surface contact because of its 7mm large bullet pins.
13. Bullet Style Connector
Usually, people know bullet-style connectors as banana plugs. These connectors come with different variations according to their different pin sizes and the current power rates also vary one them.
14. EC5 Connector
The EC5 battery connector is a large connector from the EC connector series and it supports bullet pins of 5mm size. Besides, it provides a larger surface area for contact.
15. XT90 Connector
The XT90 battery connector can take a huge load of 90A current and has a better plug-unplug system than the EC5 connector. However, exceeding the power limit by pushing more than 120A can cause a burst.
16. XT150 Connector
This XT series connector type can take a power load up to 150A and comes in a big size. For this reason, you need the large 6mm bullet pin for connection.
17. Tamiya Connector
If you need a connector for your NiMH battery, this Tamiya battery connector can be the best option for you. Different from other battery types, this connector comes with an additional lever that gives extra protection to the battery.
18. Balance Connector
For multi-cell batteries, you will need a balance battery connector. Luckily, this battery connector comes with multi-pin plugs, which help to monitor voltages and manipulate them individually.
19. HXT 4mm Connector
This HXT battery connector is perfect for high-power lithium polymer batteries. Besides, the HXT 4mm battery connector supports a current load of 93A and can handle very thick gauge wires.
Mobile Battery Connector Types
Some days ago, there were mainly removable battery-based mobile phones available on the market. Though the situation has changed a lot, still you will find many mobiles that run on removable batteries. So, a mobile battery connector is a very common scenario for maximum people, as we constantly need to connect our removable phone battery using the dedicated battery connector.
The following examples of mobile battery connectors illustrate some of the most common types of battery connectors. And, not to mention, these battery connectors are also used in tablet PCs, mobile media players, digital cameras, video cameras, navigation systems, gaming consoles, etc.
1. Low Profile Battery Connector
This battery connector is made of using a spring probe connector to improve cost-effectiveness by using fewer components.
2. 5A Low Profile Battery Connector
The 5A low-profile connector comes with a one-piece contact design and supports fast charging speeds that are used in today’s mobile devices.
3. Leaf Battery Connector
The leaf battery connector is popular for its long-stroke contact and you are assured to get flexible performance because of its pre-load contact feature.
4. Floating Battery Connector
The floating connector actually comes as a system that supports high connection and features a dual-beam floating contact function that absorbs any kind of misalignment. Because of such useful features, the floating battery connector is considered a very durable and reliable product.
Cordless Phone Battery Connector Types
Actually, the cordless phone is a telephone which is connected to landline communication without using any physical wire. We know that standard telephone sets require electrical power and a wired connection to activate and keep running.
Unlike the standard telephone set, a cordless phone runs using battery power and communicates through radio frequency transmission. And, the battery inside is connected through a battery connector. While there are a variety of battery connectors depending on the cordless phone model, we have listed the most common models below:
- B Connector
- C connector
- D Connector
- E Connector
- G Connector
- H Connector
- I Connector
- K Connector
- L Connector
- L3 Connector
- M Connector
- M0 Connector
- P Connector
- PR Connector
- P3 Connector
- Q connector
- Q3 Connector
- X Connector
- XR Connector
- Z Connector
Conclusion
In this article, we’ve covered a wide variety of battery connectors. All of these connectors have different characteristics and specifications. Also, each connector supports a specific current load and is used for a specific application. If you need a high-power battery connector, choose one that has a power load of more than 50A. Otherwise, you should go for a lower type.
